Page 7 - RAYCOH Proximity Sensor 2025V1.0
P. 7
Inductive Proximity Sensor
Universal series proximity sensor
SPECIFICATION
D6.5/M8/M12/M18/M30
Summary Table of Best-Selling Models 3
Product
Type Installation Sensing Distance NPN N.O PNP N.O Note
Dimensions
M8×30 flush 1.5mm LS-1EM08N-2S LS-1EM08P-2S
M8×30 Non-flush 2mm LN-02M08N-2S LN-02M08P-2S
M8×45 flush 2mm LS-02M08N-2 LS-02M08P-2
M8
M8×45 Non-flush 4mm LN-04M08N-2 LN-04M08P-2
M8×45 flush 3mm LS-03M08N-2 LS-03M08P-2
M8×45 Non-flush 6mm LN-06M08N-2 LN-06M08P-2
M12×50 flush 2mm LS-02M12N-2 LS-02M12P-2
M12×50 Non-flush 4mm LN-04M12N-2 LN-04M12P-2
M12×50 flush 4mm LS-04M12N-2 LS-04M12P-2
M12
M12×50 Non-flush 8mm LN-08M12N-2 LN-08M12P-2
M12×50 flush 6mm LS-06M12N-2 LS-06M12P-2
M12×50 Non-flush 10mm LN-10M12N-2 LN-10M12P-2
M18×55 flush 5mm LS-05M18N-2 LS-05M18P-2
M18×55 Non-flush 8mm LN-08M18N-2 LN-08M18P-2
M18×55 flush 8mm LS-08M18N-2 LS-08M18P-2
M18
M18×55 Non-flush 12mm LN-12M18N-2 LN-12M18P-2
M18×55 flush 12mm LS-12M18N-2 LS-12M18P-2
M18×55 Non-flush 20mm LN-20M18N-2 LN-20M18P-2
M30×55 flush 10mm LS-10M30N-2 LS-10M30P-2
M30×55 Non-flush 15mm LN-15M30N-2 LN-15M30P-2
M30×55 flush 15mm LS-15M30N-2 LS-15M30P-2
M30
M30×55 Non-flush 25mm LN-25M30N-2 LN-25M30P-2
M30×55 flush 22mm LS-22M30N-2 LS-22M30P-2
M30×55 Non-flush 40mm LN-40M30N-2 LN-40M30P-2
The connection method for the above models is a 2-meter cable. For other specifications and models, please consult a sales engineer.
High-Pressure Proximity Sensor Loop Inductive Proximity Sensor
best-seller best-seller
High-end ring
Pressure rating: 500 bar Sensing distance: 3 mm Specifications：R15/R20/R25 PNP N.O
LS-03C14N-B NPN N.O LN-15R20P-B LN-20R20P-B
LS-03C14P-B PNP N.O LN-25R20P-B
04
