Functional description

UD ultrasonic groove sensor is used to identify the printing
mode of labels and carrier materials, and the materials with
transparency and surface roughness, and can identify whether
the materials are one layer or two layers. Such as transparent
labels on transparent carrier materials and different printed
patterns on the labels.

UD ultrasonic groove sensor can identify the labels with the
minimum spacing of 2mm, and it has high positioning accuracy,
short response time and small size, which makes the groove
sensor widely used.

Teach-in function

Ÿ learning state：
①Long pressing the button time > 2s when the beginning of
UDB groove label detection the flashing green light, at this time to release the automatic
learning sheet (if successful continue to flash 3 times the
green light; if you fail to flash 3 times the red light)；
② When pressing the key for longer than 5s, switch from
Features Ÿ flashing green light to flashing yellow light. At this time,
Ÿ UDB recessed design, compact size, space- Ÿ release the automatic learning double sheets (if the green
saving identification of transparent, opaque Ÿ light flashes three times successfully; If it fails, the red light
and printed labels Ÿ flashes 3 times)；
③Double thresholds will be automatically completed when
Ÿ Response time: 250μs
Ÿ learning a single sheet, and work will start automatically
after
Details Ÿ learning. The learning function is not limited to time.
Ÿ pnp+npn switching output
Ÿ at a very fast transmission speed, it can be
Ÿ Functional signals
monitored accurately with a short response time
Ÿ the top of the sensor housing is provided with an Press 2s to teach-in single sheet
Press 5s to teach-in double sheet
LED indicator and a switch button
Ÿ by learning the teaching function, debugging is
simple and fast
Air yellow One-sheet green light double red light
Ÿ Standard working voltage DC 10-30V
Ÿ temperature compensation
Ÿ RAYCOH Tip: Pressing the button before powering on can set
Ÿ normally open and normally closed.

Ÿ Placement of the label or Ÿ Multiple labels via slot
substrate within the sensors
effective area of the
slotted sensor
