TION NOTES

Installation and operation instructions

Ultrasonic sensors can be used in harsh environments, but water droplets and excessive dust accumulation
will affect the normal output of ultrasonic waves. Fine dust and non-accumulated stains will not affect the ALLA
normal work output.
To detect the object with smooth surface and high flatness, the sensor should be installed at an angle of 90 3
with the front of the object to be detected. Prevent the installation angle from being too large, and the sensor INST
will not receive reflected sound waves.

smooth coarse Quick Selection

Main Products

Application
<3degrees >3degrees
Connotation
The surface of the object is rough, and the installation angle of the sensor can be greater than 3. Due to the
inherent characteristics of sound waves, when detecting some materials with strong sound absorption, such as Usage pattern
cotton, sponge and special cloth, the effective detection distance of the sensor will be shortened.
Features
The specific installation conditions shall be subject to on-site debugging.When selecting the type, it needs to
be tested according to different materials.
Installation Notes

Installation spacing
Accessores

Unstable
When two or more sensors of the same model are used respectively, the same frequency interference of the description
sensors will occur when they are installed too close, resulting in abnormal output of different sensors. In order
to avoid this, enough distance should be kept between multiple sensors of the same model during installation. M12

The recommended installation distance is as follows:
M18

M30
Y
Operating range x
UDA
150 300 1.5
UCC
300 400 1.8
UDB
500 500 2.5

1000 700 4.0 UR

2000 1500 10.0
Special Series
4000 3000 20.0
Square Series
6000 4000 30.0
Wireless Series

17 UGT
