Rationale

Ultrasonic sensor makes use of the characteristics of sound waves to provide a non-contact and accurate USAGE PATTERN
detection scheme for the state and distance of objects.
The sensor transmits mechanical sound waves with high frequency, and receives the sound waves reflected by
the object. By calculating the time or energy between transmitting and receiving sound waves, the accurate
distance or state of the target object can be obtained. Ultrasonic sensors are different from ordinary proximity
switches and photoelectric sensors. Compared with inductive or capacitive proximity switch, its detection
distance is longer. Compared with photoelectric sensor, it can be used in worse environment, and is not affected
by the color of the target, dust and water mist in the air Quick Selection

Ultrasonic sensors are suitable for detecting objects in different states, such as liquid, transparent materials,
Main Products
reflective materials and particles.
Application
Unaffected By Particles Not Affected By Water Mist
Connotation
Accurate Acoustic Properties
Usage pattern
Switch output,no/nc set Analog output, up/down mode set
Features
The factory default setting of the sensor is Analog voltage output type of sensor, the factory
normally open NO. default setting is that the minimum detection Installation Notes
You can switch to normally closed NC by setting distance value and the maximum detection distance
A2 point to the near side and A1 point to the far value respectively correspond to 0V and 10V of
side. analog output, which is the rising mode. Accessores
Analog current output type of sensor, factory
default setting is that the minimum detection Unstable
distance value and the maximum detection distance description
value respectively correspond to 4mA and 20mA of
analog output, which is the rising mode. M12
The analog voltage output type and the analog
current output type can be switched to the down
mode by setting the A2 point near and the A1 point M18
far side.
A1 A2 up mode A1 A2 M30
no output no output Linear output
output 10V or 20mA
0V or 4mA
UDA
blind zone blind zone UCC

10V or 20mA
Sensing range Switching hysteresis 0V or 4mA
down mode A2 A1 UDB

Digital Rs485 UR

The factory default setting of sensor is Modbus Special Series
protocol.
The agreement can be customized according to Square Series
customer requirements.
