S T 1000 ‒ 18 TM 55A ‒ N2SH101-C12.5

7
1 2 3 4 5 6 9
8
NUMBER NAME CODE & MEANING
1 S Ultrasonic sensors
T Cylindrical Basic Series
CONNOTATION
C Customised Series
RE Standard Chemical Resistance Series
2 series OD(A/C) Single & Double Detection Series
X Square Series
Quick Selection W Wireless Communication
120 120 mm
Main Products
3 Upper detection range 300 300 mm
6000 6000 mm
Application
12 Cylinder, M12mm
18 Cylinder, M18mm
Connotation
30 Cylinder，M30mm
4 Housing and mounting dimensions
Q Square Format（ U1，U9）
Usage pattern
FK Slot FK (Fk1,...)
X42 Square X42 X77 SC4 (Small square-case form factor)
Features
T M metal thread
5 Shell material
T P plastics

Installation Notes
45， 50, 55 ,60 Represents The Length Of Different Shells
6 Length & Profile
A 90-degree elbow series
Accessores
NP npn + pnp Double switch output
N2/P3 /N4/P5 Single npn or single pnp switch output
Unstable
description P6/N7 Dual pnp or dual npn switching output
U Single analog voltage 0-10V output
M12
I Single analog current 4-20mA output
IU Analog voltage 0-10 V+ analog current 4-20 mA dual output
M18 7 Electrical output
IN4 Analog voltage 4-20mA+npn dual output
UN4 Analog voltage 0-10V+npn dual output
M30
IP5 Analog voltage 4-20mA+pnp dual output
UP5 Analog voltage 0-10V+pnp dual output
SOD
R4 RS485 output
IO IO -LINK output
SRE
SH101
8 Custom Made Code XA101
SDB
……
P cable
SR
C12.4 , 4 pin M12×1
9 Connection method C8.3 , 3 pin M8×1
Special Series
C8.4 , 4 pin M8×1
Square Series C12.5 , 5 pin M12×1

Wireless Series

SGT
