Page 67 - RAYCOH_2026ENV3.0_Sensors

UR Series Digital/Analog Outputs: RS485
Detection range 30-300mm 50-500mm 60-1000mm
UR SENSOR
30
15
M18 43 30

2M

Blind zone 0-30mm 0-50mm 0-60mm
Resolution 0.17mm

Repeatability 0.15% of full-scale value 0.15% of full-scale value 0.15% of full-scale value
±1% ±1% ±1%
Absolute accuracy (Single switch output) (Single switch output) (Single switch output)
Quick Selection
Switching hysteresis 2mm
Switching frequency 45Hz 31Hz 19Hz
Main Products
Response time 22ms 32ms 52ms
Power-Up Timer Application

Operating voltage 10-30V DC， Reverse Polarity Protection 10-30V DC， Reverse Polarity Protection 10-30V DC， Reverse Polarity Protection
No target is always bright, No target is always bright, No target is always bright, Connotation
LED red ligh and no target flashes when studying and no target flashes when studying and no target flashes when studying
Detected that the target is always bright, Detected that the target is always bright, Detected that the target is always bright,
LED green light and the target flashes when studying. and the target flashes when studying. and the target flashes when studying. Usage pattern
Overpower 200mA，redlight and green light 200mA，redlight and green light 200mA，redlight and green light
protection flashing at the same time flashing at the same time flashing at the same time
Load impedance Features
No-load current
Installation Notes
Material Plastic, Polyurethane Foam Plastic, Polyurethane Foam Plastic, Polyurethane Foam
Protection class 4-pole connection 4-pole connection 4-pole connection Accessores
Connection type
Unstable
Environmental description
temperature
Storage temperature
M12
Weight 23g 23g 23g

M18
Model UR300-18GK-R4-V1 UR500-18GK-R4-V1 UR1000-18GK-R4-V1
M30

Modbus standard protocol Modbus standard protocol Modbus standard protocol
UDA
1.BN 1.BN 1.BN
UCC
3.BU 3.BU 3.BU
4.BK 4.BK 4.BK
UDB
2.WH 2.WH 2.WH

UR

Special Series

Square Series

Wireless Series

65 UGT
